Load capacity:
750 lbF [3.4 kN] at < 35 in [900 mm]/min
500 lbF [2.3 kN] at > 35 in [900 mm]/min
Maximum travel: 14.2 in [360 mm]
Standard speed range: 0.5 - 24 in/min [10 - 600 mm/min]
Optional speed range: 0.001 - 60 in/min [0.02 - 1,525 mm/min]
Speed setting accuracy: +/-0.2%
Speed variation w/ load: +/-0%
Travel accuracy: +/-0.002 in per 10 in [+/-0.05 mm per 250 mm]
Travel resolution: 0.001 in [0.02mm]
Power: Universal input 80-240 VAC, 50/60Hz, 120 W
Weight (test stand): 150 lb [68kg]
Shipping weight: 196 lb [88 kg]
