Mahr uMaxum II Digital Comparators

Mahr Inc.

Order Number:

Price: ~~$426.00~~ $404.70

Ship To:

SKU:

2034101

Mahr µMaxum Digital Comparator

Functions:

Inch/Metric - operator selectable with switchable resolution
Normal/Reverse Sensing
Preset capabilities to view actual size
"Absolute" Transducer - no overspeed errors or constant re-zeroing. Transducer always remembers its location, even if power is off.
High resolution digital readout and analog bar graph - digital display shows deviation from zero or actual dimension size (Preset)
Lightweight, contamination resistant - ruggedly built to withstand hard use - gasketed case, crystal and stem assemblies resist fluid contamination.
Calibratable - if ever needed - values remembered even after battery change.

Marconnect data output: USB, OPTO RS232C, Digimatic
Auto-power down - provides extremely low battery consumption, assuring long life from readily available commercial batteries
Increased resolution (0.0002mm / 10µinch) for today's demanding tolerances
Unilateral Tolerances
Go/NoGo Display Feature

Display Range	±0.042in ±1.067mm
Spindle Range:	-.050 to +0.060in -1.25 to 1.50mm
Resolution:	0.00001in 0.0002mm
Accuaracy: (% of range)	±0.020" range: 50µin (0.25%) ±0.040" range: 200µin (0.50%) ±0.5mm range: 1.25µm (0.25%) ±1.0mm range:5.0µm (0.50%)
Gaging Force:	3 to 4 oz (ounce) - 85 to 122 g (grams) - -at center of travel
Weight:	6 oz 170 g
Spindle Velocity:	Unrestricted
Temperature
Operating:	40° to 130°F 5° to 54°C
Storage:	0° to 140°F -17° to 60°C
Repeatability:	± 1 LSDD (Least Significant Digit)
Battery Life:	6000 hours ~ 12 months normal usage*
Contact Point:	(PT-223 radiused tip, 4-48 thread, furnished on 0.375" dia. Stem model) EPT-1037-W1 radiused tip, M2.5 thread furnished on 8mm dia. stem model
Power:	3 volt lithium coin cell (2 per unit) type CR 2450 Order# EBY-1018
Display:	Rotates through 270°
*normal usage = 12 hr/day x 7 day/wk
