M 300

MarSurf M 300
Even more comfort and performance at a good price. An investment that pays!

• Cable-free connection - Bluetooth
• Easy handling through operator prompting
• Brilliant, illuminated color display
• Integrated standard
• Measuring range of up to 350 µm (.014 in)
• Automatic selection of filter and traversing length conforming to standards
• Integrated memory for the results of up to 40,000 measurements and 30 profiles
• 15 languages

Advantages:

• Automatic selection of filter and traversing length conforming to standards
• Integrated thermal graphics printer of high print quality
• Printing of R-profile (ISO/ASME/JIS), P-profile (MOTIF), material ratio curve, measuring record
• Data transfer of results and profiles via USB-interface to your PC
• Cutoffs - 0.25/0.8/2.5mm (0.010/0.032/0.100 in)
• Integrated memory for the results of up to 40,000 measurements and 30 profiles
• Tolerance monitoring in display and measuring record
• Vertical scale: automatic/selectable
• Dynamic calibration function
• Standards: ISO/ASME/JIS and MOTIF selectable
• Number of sampling lengths selectable from 1 to 5
• Locking and/or password protection for instrument settings
• Units µm/µinch selectable
• Plug-in power pack with three mains plugs, for input voltages from 90 V to 264 V
• Output of date and/or time of the measurements

Further advantages:

• Expandable to a stationary measuring station
• Usable with the PHT series pick-ups
• Software "MarSurf PS1/M 300-Explorer" to document results and record profile
